CP-3140EX Pro

product description
• Shell Suit design
• Easy to load media
• Durable life
• Performance enhance
Tags :
  • Printer-Printing-width-4"
  • Printer-Ribbon-length-300m
Compare Inquire
  • CP-3140EX Pro Using new generation desktop printer to save time and money.Feature-rich to make daily work simple and easy.

    Shell Suit design:
    Interface roof feature can avoid interface from water spill damage and keep machine close to wall, reduce operating space.

    Easy to load media:
    Large loading space to help media and ribbon installation very easily.

    Durable life:
    Inherited the turtle spirit, integrated structure makes CP-EX Pro Series solid and robust.

    Performance enhance:
    Expanded SDRAM and Flash ROM can store more fonts, forms, graphics.
    07
  •   Printing Method Direct Thermal & Thermal Transfer
      Printing Resolution 300 dpi (12 dots/mm)
      Printing Speed Max. 4 ips
      Printing Length Max. 50”(1270 mm)
      Printing Width Max. 4.16”(105.7 mm)
      Memory 128MB SDRAM, 128MB Flash ROM
      CPU Type 32 bit RISC microprocessor
      Sensors Reflective sensor x 1 (movable) & Transmissive sensor x 1 (Center fixed)
      Operation Interface LED Indicator x 2, Button(Feed) x 1
      Communication Interface Ethernet 10/100 Mbps, USB 2.0 device, RS-232, USB 2.0 host
      Fonts Internal character sets standard 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm)
    Internal fonts are expandable up to 24x24 4 direction 0 ~ 270 rotation Soft fonts are downloadable
    Ability to print any Windows True Type font easily. Support scalable font. GB 18030 Standard (Chinese coded character set) support.
      Wireless Security N/A
      1D Barcodes PPLA: Code 39, UPC-A, UPC-E, Code 128 subset A/B/C, EAN-13, EAN-8, HBIC, Codabar, Plessey, UPC2, UPC5, Code 93, Postnet, UCC/EAN-128, UCC/EAN-128 K-MART, UCC/EAN-128 Random weight, Telepen, FIM, Interleaved 2 of 5 (Standard/with modulo 10 checksum / with human readable check digit/ with modulo 10 checksum & shipping bearer bars), and GS1 Data bar (RSS)
    PPLB: Code 39, UPC-A, UPC-E, Matrix 2 of 5, UPC-Interleaved 2 of 5, Code 39 with check sum digit, Code 93, EAN-13, EAN-8 (Standard, 2 /5digit add-on), Codabar, Postnet, Code128 subset A/B/C, Code 128 UCC (shipping container code) , Code 128 auto, UCC/EAN code 128 (GS1-128), Interleave 2 of 5, Interleaved 2 of 5 with check sum, Interleaved 2 of 5 with human readable check digit, German Postcode, Matrix 2 of 5, UPC Interleaved 2 of 5, EAN-13 2/5 digit add-on, UPCA 2/5 digit add-on, UPCE 2/5 digit add-on, and GS1 Data bar (RSS)
    PPLZ: Code39, UPC-A, UPC-E, Postnet, Code128 subset A/B/C, Interleave 2 of 5, Interleaved 2 of 5 with check sum, Interleaved 2 of 5 with human readable check digit, Code 93, Code 39 with check sum digit, MSI, EAN-8, Codabar, Code 11, EAN-13, Plessey, GS1 Data bar (RSS), Industrial 2 of 5, Standard 2 of 5, and Logmars
      2D Barcodes PPLA: MaxiCode, PDF417(Micro PDF), Data Matrix (ECC 200 only), QR code, and Composite Codes, Aztec
    PPLB: MaxiCode, PDF417, Data Matrix (ECC 200 only), QR code, and Composite Codes
    PPLZ: QR code, PDF417(Micro PDF), Data Matrix (ECC 200 only), and MaxiCode Composite Codes, Aztec
      Graphics PPLA: PCX, BMP, IMG, HEX, GDI / PPLB: PCX, BMP, Binary raster, GDI / PPLZ: GRF, HEX, GDI
      Emulation PPLA, PPLB, PPLZ
      Database Link ArgoBar Pro support ODBC Database Connection: Excel, CSV, MS Access, MS SQL, Oracle MySQL, dBASE (*.dbf)
      Software BarTender, Printer Tool, iLabelPrint+
      Drivers Windows Driver Win10/Win11, LINUX Driver, macOS Driver, Raspberry Pi Driver
      Media Type Roll-feed, die-cut, continuous, fan-fold, black mark, tags, ticket in thermal paper or plain paper
      Media Max. width: 4.65” (118mm). Min. width: 0.8” (20mm). Thickness: 0.0024”~0.008” (0.06mm~0.2mm)
    Max. roll capacity (OD): 5"(127 mm) Core size 1”(25.4mm)
    Max. roll capacity (OD): 4.5"(114.3 mm) Core size 0.5”(12.7mm)
    Max. roll capacity (OD): 4.7"(120 mm) Core size 1.5”(38.1mm)
      Ribbon Ribbon width: 1”~4.33”(25.4mm~110mm), Ribbon length: Max. 300m.
    Core size ID: 1”(25.4mm), optional: 0.5”(12.7mm), Core width: 2.6”(67mm)
    Wax, Wax/Resin, Resin (Ribbon wound ink-side out or ink-side in: auto-detect)
      Drop Resistance N/A
      Printer Dimensions W 226mm x H 188mm x D 276mm
      Printer Weight 4.6 lbs (2.1 kg)
      Power Source Universal Switching Power supply. AC input voltage: 100~240V, 50~60Hz. DC Output: 24V, 2.4A
      Battery N/A
      Operation Environment Operation Temperature: 40°F~100°F (4°C~38°C), 10% ~ 90% non-condensing,
    Storage Temperature: -4°F~122°F (-20°C~50°C)
      Real Time Clock N/A
      Standard Item N/A
      Optional Items Guillotine Cutter, Rotary Cutter, Peeler, External media stand
      Agency Listing CE, FCC, cULus, CCC, RoHS, BIS, BSMI, KC
      Attention *Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications.

    • ArgoBar_Pro_V2.18_64bits

      Barcode editing software
      Support Windows 10/11 (64-bit ) Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2 (64-bit). ​
      Support languages: English, Simplified Chinese, Traditional Chinese Argobar Pro support ODBC Database Connection: Excel, CSV, MS Access, MS SQL, Oracle MySQL, dBASE (*.dbf)

      Download

    • Printer_Tool_V1.2.20.msi

      Printer setup software
      Supports Windows 7 SP1 or later, and requires .Net Framework 4.8

      Download

    • ArgoBar_Pro_V2.18_32bits

      Barcode editing software
      Support Windows 10 (32-bit ) Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2 (32-bit). ​
      Support languages: English, Simplified Chinese, Traditional Chinese Argobar Pro support ODBC Database Connection: Excel, CSV, MS Access, MS SQL, Oracle MySQL, dBASE (*.dbf)

      Download

    • BarTender 2022 R6

      Barcode editing software
      Support Windows11, Windows 10, Windows Server 2022, Server 2019, Server2016

      Download

    • BarTender 2016 R7

      Barcode editing software
      Support Windows11, Windows 10, Windows 8 and 8.1, Windows 7, Windows Vista, Windows Server 2022, Server 2019, Server2016, Server2012 R2, Server2012, Server 2008 R2, Server 2008

      Download

    • Printer Tool V1.1.1

      Printer setup software
      Supports Windows XP or later, and requires .Net Framework 3.5

      Download

    • Font Utility V3.04

      Font tool
      This tool software can use true type font (TTF) and printer fonts.
      Supports Windows XP or later versions

      Download

    • Command Library V4.12

      Command Library V4.12 software development tool for professional users.
      Supports Windows XP or newer versions, and supports both 32-bit and 64-bit versions.

      Download

    • Argox SDK V1.4.0

      Supports Java and C# programming languages
      Supports Windows/Android/Linux operating platforms (different programming languages ​​have different support ranges, please refer to the readme.html in the SDK for details)
      Supports PPLB, PPLZ emulation.

      Download

    • iLabelPrint+ V2.3.3 Google Play

      iLabelPrint+ is a label design and printing application for mobile devices. We can use this application to easily design practical or professional labels, and output them to label paper with the connected ARGOX label printer. Support Bluetooth, LAN, WiFi, USB OTG connection on Android v8.0 and above.

      Download

    • iLabelPrint+ V2.3.3 App Store

      iLabelPrint+ is a label design and printing application for mobile devices. We can use this application to easily design practical or professional labels, and output them to label paper with the connected ARGOX label printer. Support Bluetooth, LAN, WiFi connection on iOS 13 and above.

      Download
