Ribbon wound ink-side out & ink-side in available, with 300m capacity. Twin-sensor system for diverse media types. Easy media and ribbon loading with big operation space. Unique media guide lock & media shaft design. Expanded Flash and SDRAM memory. Easy maintenance: tool-free print head & roller.
-
Printing Method Direct Thermal & Thermal Transfer Printing Resolution 203 dpi(8 dots/mm) Printing Speed Max. 7 ips Printing Length Max. 100” (2540mm) Printing Width Max. 4.1”(104mm) Memory 128MB DRAM, 128MB Flash ROM CPU Type 32 bit RISC microprocessor Sensors Reflective sensor x 1 (Movable) & Transmissive sensor x 1(Center fixed) Operation Interface LED Indicator x 2, Button(Feed) x 1 Communication Interface USB 2.0 device, RS-232, Ethernet Fonts Internal character sets standard 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) Internal fonts are expandable up to 24x24 4 direction 0 ~ 270 rotation Soft fonts are downloadable Ability to print any Windows True Type font easily Wireless Security N/A 1D Barcodes PPLA: Code 39, UPC-A, UPC-E, Code 128 subset A/B/C, EAN-13, EAN-8, HBIC, Codabar, Plessey, UPC2, UPC5, Code 93, Postnet, UCC/EAN-128, UCC/EAN-128
K-MART, UCC/EAN-128 Random weight, Telepen, FIM, Interleaved 2 of 5 (Standard/with modulo 10 checksum / with human readable check digit/ with
modulo 10 checksum & shipping bearer bars), and GS1 Data bar (RSS)
PPLB: Code 39, UPC-A, UPC-E, Matrix 2 of 5, UPC-Interleaved 2 of 5, Code 39 with check sum digit, Code 93, EAN-13, EAN-8 (Standard, 2 /5digit add-on),
Codabar, Postnet, Code128 subset A/B/C, Code 128 UCC (shipping container code) , Code 128 auto, UCC/EAN code 128 (GS1-128), Interleave 2 of 5,
Interleaved 2 of 5 with check sum, Interleaved 2 of 5 with human readable check digit, German Postcode, Matrix 2 of 5, UPC Interleaved 2 of 5, EAN-13 2/5
digit add-on, UPCA 2/5 digit add-on, UPCE 2/5 digit add-on, and GS1 Data bar (RSS)
PPLZ: Code39, UPC-A, UPC-E, Postnet, Code128 subset A/B/C, Interleave 2 of 5, Interleaved 2 of 5 with check sum, Interleaved 2 of 5 with human readable
check digit, Code 93, Code 39 with check sum digit, MSI, EAN-8, Codabar, Code 11, EAN-13, Plessey, GS1 Data bar (RSS), Industrial 2 of 5, Standard 2 of 5, and
Logmars2D Barcodes PPLA: MaxiCode, PDF417, Data Matrix (ECC 200 only), QR code, and Composite Codes
PPLB: MaxiCode, PDF417, Data Matrix (ECC 200 only), QR code, and Composite Codes
PPLZ: QR code, PDF417, Data Matrix (ECC 200 only), and MaxiCode Composite CodesGraphics PPLA: PCX, BMP, IMG, HEX and GDI format files
PPLB: PCX, BMP, Binary Raster, and GDI PPLZ: GRF, Hex and GDIEmulation PPLA, PPLB, PPLZ Software-label Editing Seagull Driver,BarTender,ArgoBar Pro Software-utility Printer Tool Driver tools Windows 10 ,Windows 11,Windows Server 2016 64-bit (x64) editions, LINUX Driver, macOS Driver, Raspberry Pi Driver Media Type Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper and fabric label Media Max. width 4.3”(110mm) Min. width 1” (25.4 mm) Thickness 0.0025”~0.01” (0.0635mm ~0.254mm) Max. roll capacity (OD): 6"(152.4mm) Core size 1"/1.5"(25.4 or 38.1mm) Max.roll capacity (OD): 4.5"(114.3 mm) Core size 0.5”(12.7mm) Optional Max. roll capacity (OD): 4.7"(120 mm) Core size 1.5”(38.1mm) Optional Ribbon Ribbon roll – OD: 2.6”(67mm) Ribbon Length: Max. 300m Core size: 1” (25.4 mm) Ribbon Width: 1"~4.33"(25.4mm~110mm) Wax, Wax/Resin, Resin (Ribbon wound ink-side out or ink-side in) Drop Resistance N/A Printer Dimensions W 220mm x H 216mm x D 322mm Printer Weight 2.1 kgs Power Source Universal Switching Power Supply Input: 100V~240V±10%, 1.8A, 50~60Hz, Output: 24VDC, 2.5A Battery N/A Operation Environment Operation Temperature: 40°F~100°F (4°C~38°C), 0% ~ 90% non-condensing, Storage Temperature: -4°F~122°F (-20°C~50°C) Real Time Clock N/A Standard Item N/A Optional Items Media Stacker, Full Cutter, Partial Cutter, Peeler, RTC Card Agency Listing CE, FCC, CCC, RoHS, BSMI Attention *Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications. -
-
